Specification
|
General |
|
|
Model Number |
WT-368 |
|
Frequency Range |
VHF: 136-174MHz UHF:400-470MHz |
|
Power |
10W |
|
Channel Capacity |
16 |
|
Battery Capacity |
Li-ion 4200mAh |
|
Working Voltage |
DC 7.4V |
|
Antenna Impedance |
50Ω |
|
Weight (Include battery) |
300g |
|
Size(Include antenna) |
120x56x39mm |
|
Transmitter |
|
|
Output Power |
10W/5W |
|
The Maximum Deviation |
≤5KHz |
|
Residual Radiation |
<60dB |
|
Current |
≤1000mA |
|
Audio Response |
+7~-12.5dB |
|
Receiver |
|
|
Sensitivity |
≤0.16μV(12dB SINAD) |
|
Squelch Sensitivity |
<0.2μV |
|
Intermodulation |
50dB |
|
Audio Power |
≥300mW |
|
Current |
≤100mA |
|
Squelch Current |
20mA |
Functions
High performance voice processing
10W high output power
VOX hands free
Tail Tone Elimination
Auto Battery Save
Monitor
Busy Channel Lockout
CTCSS/DCS jump code
TOT(time out timer)
High solution audio quality
50 CTCSS/208 DCS
Scanning
Alarm Function
Application site
Package and shipping
By air/sea or by express, for small order we suggest you can consider sent by express like DHL, FedEx, UPS etc.
1. UPS, DHL, EMS, HK EMS, FEDEX, HK post, TNT and so on (door to door)
2. Express shipping period varies depending upon your location. Normally, it will take around 3-7days from China to destination country, but some remote places need more 1-3 days.
3. We only ship to the confirmed address provided. Please make sure the Ship-To address you type during checkout is correct. We are not responsible for any wrong or undeliverable addresses.
4. Custom fee (including VAT&GST):
Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office before bidding. We will try our best to help customer do customs clearance.
