Specification
|
General |
|
|
Model Number |
WT-Z9 |
|
Frequency Range |
GSM:EGSM900MHz DCS1800MHz CDMA2000/EVDO:BC0 WCDMA:BAND1&BAND8 TD-SCDMA:1.9G 2G LTE-FDD:BAND1&3&8 LTE-TDD:BAND38&39&40&41 |
|
Battery Capacity |
Li-ion 5500mAh |
|
Working Voltage |
DC 3.7V |
|
Antenna Impedance |
50Ω |
|
Weight (Include battery) |
320g |
|
Size(Include antenna) |
112x53x36mm |
|
TX POWER |
|
|
GSM/GPRS Power Level |
EGSM900: 4 (2W)DCS1800: 1 (1W) |
|
EDGE Power Level |
DGSM900: E2 (0.5W)DCS1800: E1 (0.4W) |
|
CDMA 1X Power Level |
3 (0.25W) |
|
UMTS Power Level |
WCDMA: 3 (0.25W) EVDO: 3 (0.25W) TD-SCDMA: 2 (0.25W) |
|
LTE Power Level |
3 (0.25W) |
|
RX sensitivity |
|
|
EGSM900 |
＜-109dBm |
|
DCS1800 |
＜-109dBm |
|
WCDMA 2100 |
＜-110dBm |
|
WCDMA 900 |
＜-109dBm |
|
TDSCDMA 1900 |
＜-109dBm |
|
TDSCDMA 2000 |
＜-109dBm |
|
CDMA BC0 |
＜-109dBm |
|
LTE FDD/TDD |
＜-110dBm |
1.Selective Call,Group Call and All Call
2.Big LCD screen
3.Audio quality standard/enhanced select
4.Software version update
2.Ultra High Capacity 5500mAh Li-ion Battery
3.Desk charger and USB adapter available
4.Network Signal Strength Prompt
5.Voice Prompt Authority Setting
6.GPS Function (Optional)
Application site
Package and shipping
By air/sea or by express, for small order we suggest you can consider sent by express like DHL, FedEx, UPS etc.
1. UPS, DHL, EMS, HK EMS, FEDEX, HK post, TNT and so on (door to door)
2. For air shipment, please choose your favorite shipping method according to your requirements
3. We will prepare the shipment in 24-72 hours after we receive the payment and after the check is cleared.
4. Package: Inner Packaing:Retail packaging, single packaging, or according to customer's advise.
Outer Packaing: Strong carton, Shipping Mark as customer's advise.
