Specification
|
General |
|
|
Model Number |
WT-C3 |
|
Frequency Range |
UHF:400-480MHz |
|
Power |
3W |
|
Channel Capacity |
16 |
|
Battery Capacity |
Li-ion 1600mAh |
|
Working Voltage |
DC 3.7V |
|
Antenna Impedance |
50Ω |
|
Weight (Include battery) |
120g |
|
Size(Include antenna) |
112x53x36mm |
|
Transmitter |
|
|
Output Power |
3W/0.5W |
|
The Maximum Deviation |
≤5KHz |
|
Residual Radiation |
<60dB |
|
Current |
≤1000mA |
|
Audio Response |
+7~-12.5dB |
|
Receiver |
|
|
Sensitivity |
≤0.16μV(12dB SINAD) |
|
Squelch Sensitivity |
<0.2μV |
|
Intermodulation |
50dB |
|
Audio Power |
≥300mW |
|
Current |
≤100mA |
|
Squelch Current |
20mA |
Functions
Auto Battery Save
Low Battery Alert
Busy Channel Lockout
Wide/narrow bandwidth selective (PC program)
squelch level 0-9 adjustable
TOT (Time-out timer)
Channel Scan
Application site
Package and shipping
By air/sea or by express, for small order we suggest you can consider sent by express like DHL, FedEx, UPS etc.
1. We only ship to the confirmed address provided. Please make sure the Ship-To address you type during checkout is correct. We are not responsible for any wrong or undeliverable addresses.
2. For air shipment, please choose your favorite shipping method according to your requirements
3. We strive our best to provide you the most reliable, affordable way of shipping service. But sometimes international delivery is highly depended on the Courier Company and local customs/duties. If you do not receive your item on time, please contact us immediately for further assistance. Thank you for your understanding.
4. Express shipping period varies depending upon your location. Normally, it will take around 3-7days from China to destination country, but some remote places need more 1-3 days.
