Specification
|
General Technical |
|
|
Model Number |
RM-CHR977 |
|
Frequency range |
136MHz-174MHz 350MHz-400MHz 400MHz-470MHz |
|
Channel spacing |
12.5kHz |
|
Modulation |
4FSK |
|
Channels |
16 |
|
Impedance of antenna |
50Ω |
|
Carrier frequency error |
≤0.5ppm |
|
Duty cycle |
100% |
|
Working voltage |
AC:100V-240V |
|
Working current (standby) |
AC:≤1A |
|
Working current (TX) |
AC:≤4A |
|
Working temperature |
-30℃～+60℃ |
|
Store temperature |
-40℃～+85℃ |
|
Weight |
≤8.5kg |
|
Dimension |
44X483X341mm |
|
RX part |
|
|
Sensitivity |
≤-120dBm，error code rate 5% |
|
Adjacent channel selectivity |
≥65dB @ 12.5KHz |
|
Inter-modulation attenuation |
≤-50dB， ≤-70dB |
|
Spurious response |
≥70dB @ 12.5 |
|
Blocking |
≥90dB |
|
Common channel suppression |
≥-12dB，error code rate <5% |
|
conducted spurious emission |
≤-57dBm（No TX，9kHz～1GHz） |
|
≤-47dBm（No RX，1GHz～12.75GHz） |
|
|
TX part |
|
|
Output power |
5W-50W (VHF);5W-40W (UHF) |
|
4FSK Modulation |
12.5kHzdata only：7K60FXD 12.5kHz data and audio：7K60FXW |
|
4FSK Modulation Frequency Offset |
≤5.0% |
|
spurious emission |
-36dBm≤1GHz -30dBm>1GHz |
|
Maximum modulation limit |
±2.5 kHz |
|
Modulation of adjacent channel power |
≤-60dB（±12.5kHz） |
Functions
l DMR
l IP site connect
l Single call, group call,all call and data repeating
l Upgraded by software
l Data control by WEB built-in
